Please check our latest how-to and learn in the shortest time how to debug SysML simulations.

1. Common Issues

• Incorrect or incomplete SysML model

  • To execute action you require tokens in all action inputs

  • State does not stays active if transition from state has no trigger or guard

  • No signals on sent / accept event actions

  • Parametric diagram constraint block parameters are not connected

• Elements in the model are not the same as in the diagram

  • Deleted symbol from diagram but not from the model (use Ctrl + D)

  • Copy pasted symbol in diagram.. Element is still the same
• No classifier behavior is assigned

• Classifier behavior is assigned but execution is not in context

• Variable names does not match


2. Common Time Issues

• Time parameters are not specified

• Clock does not start

• No duration constraints – time is based on animation speed

• Chart refresh rate is too high


3. Animation
4. Breakpoints
5. Runtime Value Monitoring, Watch Pane
6. Console pane
7. Rule #1 - Large Simulation - Fast Debugging!
