2026x Dassault Systemes sample Starterkit for Tubing hydraulic 3D Design, cover limited number design rules, spec and Tubing Parts.

The idea of this Resource Set is to have a light setup that can be

• imported on Cloud with no limitation (47k objects maximum can be imported on Cloud)
• easily used for any Tubing Hydraulic Demonstration.
• used as reference (with good component definition practice) for customer implementation
  • see here for more details about component definition practice

Both Standard are build exactly the same way :

• 2 Standards :  IMPERIAL / METRIC
• 2 material categories : Stainless Steel, Titanium
• Size Range : 1/4in->1 1/2in / 6mm->20mm
• Connection type :
  • Flareless : SAE / ISO8434-1
  • Flared : SAE JIC / ISO8434-2
  • Flanged : SAE / ISO6164
• Rating Range : 3000# -> 6000# / SerieL - SerieS

Description of Component Subtypes, Endtyles and connections assemblies :

StarterKit 3DXML

Video of Usage

to come
